3mm Series
产品详情
应用领域
状态指示器、家用和智能电器、工业控制面板、可穿戴和便携式设备
Water clear
| Part Number | Emitting Color | Wavelength(nm)/TYP | Luminous Intensity(mcd)/TYP | Viewing Angle (2θ ½） | Lens Color | Size(mm) | DataSheet |
| GL3042RDD-122 |  Red | 620 | 200 | 60 | Red Diffused | Φ3.0*5.3 | |
| GL3042ODD-122 |  Orange | 605 | 200 | 60 | Orange Diffused | Φ3.0*5.3 | |
| GL3042YDD-122 |  Yellow | 590 | 200 | 60 | Yellow Diffused | Φ3.0*5.3 | |
| GL3042YGDD-122 |  Yellow Green | 570 | 50 | 60 | Green Diffused | Φ3.0*5.3 | |
| GL3042GDD-132 |  Pure Green | 525 | 3000 | 60 | Green Diffused | Φ3.0*5.3 | |
| GL3042BDD-132 |  Blue | 465 | 500 | 60 | Blue Diffused | Φ3.0*5.3 | |
| GL3042WDD-132 |  White | x:0.28,y:0.28 | 6000 | 60 | White Difffused | Φ3.0*5.3 |
